Fuse Accessories V Clamp

Product Description

PRODUCT DESCRIPTION:
V-Clamp consist from profile, or profiled material with one screw and one pad installed on screw.
V-Clamps are usually used together with streamer(prism A8) to creat electrial connection between wire and contact.Streamer is installed or mounted on side of contact and V-Clamp pressing a cable to streamer and it creats electrical connection.
Together it creates very fast and effective way how to connect cable to various range of low voltage devices such as cabinets,fuse links,fuse disconnector,bus bar systems and many others.

PRODUCT RANGE:
V Clamp FA 2 -VC RM, RE, SM, SE *****0 mm reversible pad Non reversible
V Clamp FA-VCN RM, RE, SM, SE *****0 mm not reversible pad
miniV Clamp FA-mV RM, RE, SM, SE ****0 mm
Steel V clamp FA-Fe-VC RM, RE, SM, SE *****0 mm
Steel miniV-Clamp FA-Fe-mV RM, RE, SM, SE ****0 mm
Stainles mini V Clamp FA-SS-mV RM, RE, SM, SE ****0 mm
V-Cover FA-VCover Cover for FA-VC, FA-VCN, FA-Fe-VC
CRZC****5

CRKR****5

CRKR****5

USED MATERIALS:
V-Clamp - Al alloy, Al or brass bridge nickel tinned.
Steel V-Clamp - Fe alloy w. HDG., bridge brass nickel tinned or Fe with HDG.

VARIANTS:
Variant of the product is also manufactured and supplied in modification's as is showed upwards in PRODUCT RANGE.

STORANGE AND TRANSPORT:
Product do not have any specific requirements on storage. It is fire-resistant and it is not dangerous.
