sand washer / log washer sand washing machine

FOB Price

Get Latest Price

1000 ~ 10000 USD / Set ( Negotiable )

1 Set Minimum Order

Country:

China

Model No:

2RXL

FOB Price:

1000 ~ 10000 USD / Set ( Negotiable )(Negotiable) Get Latest Price

Place of Origin:

Jiangxi, China

Price for Minimum Order:

1000 per Set

Minimum Order Quantity:

1 Set

Packaging Detail:

exporting packing standard

Delivery Time:

Within 7 days after the down payment

Supplying Ability:

500 Set per Month

Payment Type:

L/C, T/T

Product Group :

Contact Now

Jiangxi Hengcheng Mining Equipment.Co., LTD

China

Free Member

Contact Person Zack

Guzhang Industrial Park, Ganzhou, Jiangxi

Contact Now

Product Specification

Power(W):4-55kw
Capacity(t/h):10-100 t/h
Place of Origin:Jiangxi, China (Mainland)
Model Number:2RXL
Weight:0.9-23t,0.9-18.9 t
Certification:ISO9001,ISO9001-2008
Warranty:1 year
Sale service:For whole using life
Feeding size:<=30-70
Rotating speed:21-28 r/min

Product Description

Description of Log washer

Log Washers are ideal for scrubbing difficult material, Tough insoluble clays, conglomerates and soft stone, and aggregates

Features

Log Washers ideal for scrubbing difficult materials such as tough insoluble clays, conglomerates, soft stone and

cemented aggregate

·High capacity

·Heavy duty conveying paddles

·Fabricated with heavy duty tubs

·Oversize bearings and gears

·Thick-walled shafts

·Lower end bolted to fully machined stub shaft. Upper end mounted through flexible coupling to output shaft of gearbox

·The compound drive divides the operating load over an optimal combination of oversized helical and spur gears

·Continuous grinding and abrading log washer paddles

·Adjustable water discharge gates on both sides of lower end of the tub

Descriptions
Our Log Washers are ideal for scrubbing difficult material. Tough insoluble clays, conglomerates and soft stone, and certain cemented aggregates are too difficult to clean properly in normal screw machines. The log washer thoroughly scouring, breaks down, and cleans the toughest materials. These high quality, highly durable machines perform well under the toughest clay conditions with minimum power, water and downtime.

Feed material is normally delivered between two to four feet from the feed end of the box and is subjected to an aggressive washing action resulting from the intermeshing paddle design. The paddles perform two functions: they help convey material and are the catalyst to material on material scrubbing. The clean material works uphill, between the shafts, and is discharged out the bottom of the box. Deleterious materials are absorbed into water and carried over a weir on either side of the box. The length of

the washer box is dependent upon the percentage and tenacity of clay or the waste to removed.

Technical Specifications

Model	Spiral Dia. (mm)	Rotating Speed (r/min)	Feeding size (mm)	Tank slope (o)	Output (t/h)	Power (kw)	Weight (t)
2RXL**0	Φ0×*0	*8	≤*0	≤*2	*0	4	0.9
2RXL**0	Φ0×*0	*3	≤*0	≤*2	*0	5.5	1.9
2RXL**0	Φ0×*0	*3	≤*0	≤*2	*5	7.5	3.9
2RXL**0	Φ0×*0	*2.7	≤*0	≤*2	*0	*0	*7.2
2RXL**0	Φ0×*0	*2	≤*0	≤*2	*0	*5	*8.9
2RXL**4	Φ4×*0	*1	≤*0	≤*2	**0	*5	*3

Country:	China
Model No:	2RXL
FOB Price:	1000 ~ 10000 / Set ( Negotiable ) (Negotiable) Get Latest Price
Place of Origin:	Jiangxi, China
Price for Minimum Order:	1000 per Set
Minimum Order Quantity:	1 Set
Packaging Detail:	exporting packing standard
Delivery Time:	Within 7 days after the down payment
Supplying Ability:	500 Set per Month
Payment Type:	L/C, T/T
Product Group :	-
